LCD-GD-Boats Overview

The boat dualband GSM Signal Booster Nikrans LCD-GD-Boats is used to improve GSM signals in different kinds of boats. The marine repeater has an omnidirectional outside antenna which makes possible to receive signal in 360° degrees around the ship from providers’ antennas. The distance from the coastline can be up to 40 km. The coverage area of LCD-GD-Boats with one inside antenna reaches 1200m² (13000ft²), which is sufficient for medium and large-sized yachts and boats. However, if necessary, you will be able connect to the booster up to 4 inside antennas, which is a good idea for yachts with several rooms, for example. The number of users who can benefit from the signal amplified by the booster is unlimited.

This booster model works at two frequency ranges simultaneously - at GSM 900MHz and DCS 1800MHz. Both frequencies are typical for mobile providers from Europe, Asia and Africa. The device is able to provide incoming and outgoing calls without interruptions. It will also guarantee perfect functioning of mobile data transfer on condition that your provider supports 3G at 900MHz band or/and LTE 4G at 1800MHz.

Among unique and useful features of LCD-GD-Boats dualband booster there are:

LCD displays. You’ll see all the necessary setup tips on the screens, which will help you install the system fast and easily. The left screen displays info for 900MHz band, while the right one shows data for 1800MHz band.
Energy saving.The device goes into stand-by mode during non-functioning periods, which helps save energy and your budget a lot.
Gain and signal adjustment. Basing on the strength of incoming signals, the system self-adjusts system gain and signal power for the best result.
Two power supply types (12V and 220V) which will give you the opportunity to choose the one suiting you the best.

This mobile amplifier corresponds to the modern technical standards which is proved by the international CE and RoHS certifications.

Purchase this LCD booster for boat and ensure stable phone communication when you’re on the move!

The model is delivered in full package comprising inside and outside antennas, signal amplifier and all the necessary mobile phone mounts for boats. Thanks to the LCD screen with setup tips, the installation of the amplifier is so easy that you can fix it on your own just in 10-15 minutes. This dualband gsm marine repeater 12v is also very convenient in use. The coverage becomes perfect all over your boat automatically in 5-7 seconds after installation of the system.

The device is considered to be safe for human health. Moreover, it reduces radiation background as a cell phone emits twice much more trying to find a stable signal.

Nikrans LCD-GD-Boats GSM repeater is the best way to ensure stable mobile communications for people spending much time offshore!

Our Professional Team is always ready to answer all your questions.

LCD-GD-Boats Specification

Coverage: ·

Up-link freq:890-915MHz & 1710-1785MHz

Down-link freq:935-960MHz & 1805-1880MHz

Up-link Gain:75 dB

Down-link Gain:80 dB

Power Output:20 dBm

Working t °C:-25/+55 °C

Humidity:5 - 95 %

Size (mm):129*95*30mm

Booster Weight:4.2 kg

Power supply:Input AC90~264V,output DC5V/2A

Model Year:2018
